Feature
- FFP Scope
- Edge-to-Edge Image
- 2 Levels Red Illumination
- On/OFF Switch
- Etched SVD Style Reticle
- W/ Ocular Lens Eye Cover
- Side Mount System
Specification
- Magnification: 4x
- Objective Lens: 24mm
- Ocular Lens Dia: 38mm / 1.5in
- Ocular Length: 49mm / 1.9in
- Exit Pupil: 6.0mm
- Length: 270mm / 10.6in
- Weight (net): 521g / 18.4oz without lens caps
- Eye Relief: 80mm / 3.15in
- Field of View (@100yds): 20 ft@100yds
- Optics Coating: Fully-multi coated
- Reticle: SVD reticle
- Click Value: 0.5MIL
- Evaluation Range: 18MIL
- Windage Range: 18MIL
- Parallax Setting: 100 Yds
- Finish:Black
- Illumination: 2 levels red
- Battery: CR2032
- Shockproof: 500g
- Water resistant: IPX4
- Material: high quality die cast aluminum
- Completely sealed and nitrogen filled for water resistant, fogproof and shockproof performance.
- Including items: instruction, ocular lens eye cover, lens caps and cleaning cloth etc.
Reticle
Service
