- Vector Optics Top Premium Line That Can Compete Most Worldwide Famous Brand Optics.
- 34mm Monotube Made of 6061 T6 Aluminum Alloy, First Focal Plane Scope HD Glass.
- German Optics System by Using LaREE Lens & VePRO FMC > 90% Light Transmission.
- Very Little Distortion, Extra-Low Dispersion, Excellent for Dawn, Dusk Even at Night Shooting.
- True 6x Zoom Factor, Constant 4 Inch Eye Relief without Inside Dark Ring Around Image.
- 6 Levels Red Illumination, Side Focus Parallax Min Starts from 10 Yards to Infinite Range.
- Adjustment System Made of 7075 T6 That Never Snag on Anything and Never Get Turned.
- 1/10MIL Adjustment, Zero Stop & Turret Lock, 100 Clicks per Round, 44MIL Elevation Range.
- Etched Glass VEC-MBR Tactical MIL Reticle, Center Dot Illuminated with Digital Lines & Dots.
- Take Lapua Magnum 338 Recoil and All Fields of Application for Hunting, Sporting & Competition.
Magnification | 3-18x |
Objective Lens Dia | 50 mm |
Focal Plane: | FFP |
Tube Dia | 34 mm Monotube |
Eye Relief: | 100 mm / 4.0 in |
Exit Pupil | 8.0 - 2.8 mm |
Lens Coating | Fully Multi-coated |
Linear Field of View @ 100 yd | 40.8-6.8 ft @100 yards |
Linear Field of View @ 100 m | 13.6-2.3 m @ 100 meters |
Side Focus | 10 yards to Infinity |
Reticle | Etched Glass VEC-MBR |
Click Value | 1/10 MIL |
Turret Function | Zero Stop, Turret Lock |
Elevation Adjustment Range | 44 MIL |
Windage Adjustment Range | 16 MIL |
Diopter Compensation | (+2 to -3) |
Illumination Setting | 6 Gear, Red |
Battery Type | CR2032 |
Waterproof | IP67 |
Fogproof | Filled Nitrogen |
Shockproof | 1000 G |
Housing Material | 6061 T6 Aluminum Alloy |
Length | 338 mm / 13.3 in |
Weight | 790 g / 27.9 oz |
Items in the Package | One Pair of 34 mm Picatinny Scope Rings, Spare Common Elevation Turret, Sunshade, Instruction, etc. |
- Vector Optics Top Premium Line That Can Compete Most Worldwide Famous Brand Optics.
- 34mm Monotube Made of 6061 T6 Aluminum Alloy, First Focal Plane Scope HD Glass.
- German Optics System by Using LaREE Lens & VePRO FMC > 90% Light Transmission.
- Very Little Distortion, Extra-Low Dispersion, Excellent for Dawn, Dusk Even at Night Shooting.
- True 6x Zoom Factor, Constant 4 Inch Eye Relief without Inside Dark Ring Around Image.
- 6 Levels Red Illumination, Side Focus Parallax Min Starts from 10 Yards to Infinite Range.
- Adjustment System Made of 7075 T6 That Never Snag on Anything and Never Get Turned.
- 1/10MIL Adjustment, Zero Stop & Turret Lock, 100 Clicks per Round, 44MIL Elevation Range.
- Etched Glass VEC-MBR Tactical MIL Reticle, Center Dot Illuminated with Digital Lines & Dots.
- Take Lapua Magnum 338 Recoil and All Fields of Application for Hunting, Sporting & Competition.
-
VEC-MBR Reticle Manual
-
34mm Continental FFP User Manual Spanish
-
34mm Continental FFP User Manual Hungarian
-
34mm Continental FFP User Manual Portuguese
-
34mm Continental FFP User Manual Italian
-
34mm Continental FFP User Manual Polish
-
34mm Continental FFP User Manual Norwegian
-
34mm Continental FFP User Manual Russian
-
34mm Continental FFP User Manual German
-
34mm Continental FFP User Manual Japanese
-
34mm Continental FFP User Manual Dutch
-
34mm Continental FFP User Manual French
-
34mm Continental FFP User Manual English
SPECIFICATION
Magnification | 3-18x |
Objective Lens Dia | 50 mm |
Focal Plane: | FFP |
Tube Dia | 34 mm Monotube |
Eye Relief: | 100 mm / 4.0 in |
Exit Pupil | 8.0 - 2.8 mm |
Lens Coating | Fully Multi-coated |
Linear Field of View @ 100 yd | 40.8-6.8 ft @100 yards |
Linear Field of View @ 100 m | 13.6-2.3 m @ 100 meters |
Side Focus | 10 yards to Infinity |
Reticle | Etched Glass VEC-MBR |
Click Value | 1/10 MIL |
Turret Function | Zero Stop, Turret Lock |
Elevation Adjustment Range | 44 MIL |
Windage Adjustment Range | 16 MIL |
Diopter Compensation | (+2 to -3) |
Illumination Setting | 6 Gear, Red |
Battery Type | CR2032 |
Waterproof | IP67 |
Fogproof | Filled Nitrogen |
Shockproof | 1000 G |
Housing Material | 6061 T6 Aluminum Alloy |
Length | 338 mm / 13.3 in |
Weight | 790 g / 27.9 oz |
Items in the Package | One Pair of 34 mm Picatinny Scope Rings, Spare Common Elevation Turret, Sunshade, Instruction, etc. |
FEATURE
- Vector Optics Top Premium Line That Can Compete Most Worldwide Famous Brand Optics.
- 34mm Monotube Made of 6061 T6 Aluminum Alloy, First Focal Plane Scope HD Glass.
- German Optics System by Using LaREE Lens & VePRO FMC > 90% Light Transmission.
- Very Little Distortion, Extra-Low Dispersion, Excellent for Dawn, Dusk Even at Night Shooting.
- True 6x Zoom Factor, Constant 4 Inch Eye Relief without Inside Dark Ring Around Image.
- 6 Levels Red Illumination, Side Focus Parallax Min Starts from 10 Yards to Infinite Range.
- Adjustment System Made of 7075 T6 That Never Snag on Anything and Never Get Turned.
- 1/10MIL Adjustment, Zero Stop & Turret Lock, 100 Clicks per Round, 44MIL Elevation Range.
- Etched Glass VEC-MBR Tactical MIL Reticle, Center Dot Illuminated with Digital Lines & Dots.
- Take Lapua Magnum 338 Recoil and All Fields of Application for Hunting, Sporting & Competition.
SIZE
DOWNLOAD
-
VEC-MBR Reticle Manual
-
34mm Continental FFP User Manual Spanish
-
34mm Continental FFP User Manual Hungarian
-
34mm Continental FFP User Manual Portuguese
-
34mm Continental FFP User Manual Italian
-
34mm Continental FFP User Manual Polish
-
34mm Continental FFP User Manual Norwegian
-
34mm Continental FFP User Manual Russian
-
34mm Continental FFP User Manual German
-
34mm Continental FFP User Manual Japanese
-
34mm Continental FFP User Manual Dutch
-
34mm Continental FFP User Manual French
-
34mm Continental FFP User Manual English
RETICLE
