· 3MOA Dot Size with 8 Levels Red Dot Intensity, 7 Daylight and 1 NV.
· Unlimited Eye Relief, 38mm 1.5in From Bottom to the Dot Sight Center.
· 1MOA Capped Adjustment w/ Audible Click, QD Mount, Graphite Finish.
| Magnification | N/A |
| Objective Lens Dia | 20 mm |
| Parallax | Free (<1 MOA) |
| Parallax Setting | |
| Dot Size | 3 MOA |
| Sensor | N/A |
| Click Value | 1 MOA |
| Elevation Adjustment Range | >60 MOA |
| Windage Adjustment Range | >60 MOA |
| Footprint | |
| Mounting Rail | Picatinny |
| Illumination Setting | 7 Daylight + 1 Night Vision |
| Battery Type (NOT INCLUDE) | CR2032 |
| Battery Life | |
| Battery Placement | |
| Waterproof | IPX4 |
| Shockproof | |
| Working Temperature | -20~+55° C |
| Housing Material | 6061-T6 Aluminum Alloy |
| Mount Material | 6061-T6 Aluminum Alloy |
| Finish | Black Matte |
| Weight (Net) | 190 g / 6.7 oz |
| Items in the Package | QD Picatinny mount, Low Picatinny Mount, Flip-up Caps, Hex Keys and Cleaning Cloth, etc. |
FEATURE
· 3MOA Dot Size with 8 Levels Red Dot Intensity, 7 Daylight and 1 NV.
· Unlimited Eye Relief, 38mm 1.5in From Bottom to the Dot Sight Center.
· 1MOA Capped Adjustment w/ Audible Click, QD Mount, Graphite Finish.
SPECIFICATION
| Magnification | N/A |
| Objective Lens Dia | 20 mm |
| Parallax | Free (<1 MOA) |
| Parallax Setting | |
| Dot Size | 3 MOA |
| Sensor | N/A |
| Click Value | 1 MOA |
| Elevation Adjustment Range | >60 MOA |
| Windage Adjustment Range | >60 MOA |
| Footprint | |
| Mounting Rail | Picatinny |
| Illumination Setting | 7 Daylight + 1 Night Vision |
| Battery Type (NOT INCLUDE) | CR2032 |
| Battery Life | |
| Battery Placement | |
| Waterproof | IPX4 |
| Shockproof | |
| Working Temperature | -20~+55° C |
| Housing Material | 6061-T6 Aluminum Alloy |
| Mount Material | 6061-T6 Aluminum Alloy |
| Finish | Black Matte |
| Weight (Net) | 190 g / 6.7 oz |
| Items in the Package | QD Picatinny mount, Low Picatinny Mount, Flip-up Caps, Hex Keys and Cleaning Cloth, etc. |
SIZE
RETICLE
DOWNLOAD
