Feature
Edge-to-Edge Image without Inside Dark Ring Around Image, 3.8in Long Eye Relief
30mm Monotube Made of 6061 T6, 1/2 MOA Capped Adjustment, Power Lever Mount
Fully-multi Coated, Wide Field of View, Red & Green Illumination, with Flip-up Caps
Etched Glass Illuminated BDC Crossbow Reticle w/ Digital Lines & Dots, 300-475 FPS
Specification
·Magnification: 2-5x
·Objective Lens Dia: 24mm
·Ocular Lens Dia: 36mm / 1.4 inch
·Ocular Lens Length: 60mm / 2.4 inch
·Exit Pupil: 10.7-4.8mm
·Optics Coating: Fully multi coated
·Field of View: 63.7-25.5 feet@ 100 yards
·Eye Relief: 96mm / 3.8in
·Length: 248mm / 9.8in
·Weight: 380g / 13.4oz
·Tube Dia: 30mm
·Click Value: 1/2MOA
·Adjustment Range: >60MOA
·Parallax Setting: 30 yards
·Reticle: Etched glass VCB-CDO
·Illumination: 5 levels red & green
·Battery Type: CR2032
·Finish: Black matte
·Shock tested to 750g, water resistant IPX4
·Fully nitrogen purged to eliminate any fogging of the lenses internally
·Capped adjustment with zero re-set feature
·High quality 6061 T6 aircraft grade aluminum
·Diopter compensation from fast-focus eyepiece (+2 to -2)
·Including items: power ring lever mount, 30mm weaver low rings (default) or dovetail rings, flip-up caps and cleaning cloth etc.
