Feature
- 25.4mm 1“ Tube, Multi-Coated
- 1/4 MOA
- Red & Green Illumination
- w/ Lens Caps
Specification
-
Magnification:3-9x
-
Objective Lens Dia:40mm
-
Ocular Lens Dia.:28mm
-
Exit Pupil:13.3-4.4mm
-
Optics Coating:Multi coated
-
Field of View:11.5-34.9 feet @ 100 yards
-
Eye Relief:50-45mm (2.0-1.8")
-
Length:190mm (7.5 inch)
-
Weight:330g (11.6oz)
-
Tube Dia.:25.4mm 1"
-
Click Value:1/4 MOA
-
Elevation Range:90MOA
-
Windage Range:90MOA
-
Parallax Setting:100 yards
-
Reticle:Mil-dot (H)
-
Material:6063-T6 alluminum alloy
-
Illumination:5 red & green
-
Battery:CR2032
-
Distance between middle turret part to power ring: 23mm (0.9 inch)
-
Recoil fit 223 and 5.56mm
-
Distance between middle turret part to objective lens: 20mm (0.8 inch)
-
Diopter compensation from fast-focus eyepiece (+2 to -3)
-
Including items: 25.4 weaver ring, lens caps and cleaning cloth etc.
