Feature
30mm Monotube, Ultra Short 295mm 11.6", 1/10MIL 1cm Adjust With Turret Lock System
Fully Multi Coated, Side Focus Min @ 10 Yds, Long Eye Relief, Six Gear Red Illumination
Center Dot Illuminated Etched Glass Reticle, w/ Honeycomb Sunshade, Flip Up Caps
" A Must for Your Compact Air Guns and Light Weight Firearms, The Shortest Marksman Scope for You."
Reticle
Specification
Magnification: 6-24x
Objective Lens Dia: 44mm
Ocular Lens Dia: 33mm
Ocular Lens Length: 35mm
Exit Pupil: 7.3-1.8mm
Optics Coating: Fully-multi coated
Field of View: 17.5-4.3 feet@ 100 yds
Eye Relief: 90-85mm / 3.5-3.4"
Length: 297mm / 11.7"
Weight (net): 585g / 20.6oz
Tube Dia: 30mm Monotube
Click Value: 1/10MIL, 1cm
Elevation Range: 14.5MIL
Windage Rang: 14.5MIL
Parallax Adjustment: 10 yards to infinite
Reticle: Etched glass MPR-V5
Finish: Black matte
Illumination: Six gear
The distance between objective lens part and middle turret: 50mm (2.0 inches)
Length of middle turret part: 37mm (1.4 inches)
The distance between middle turret part to power ring: 30mm (1.2 inches)
Shock tested to 750g, IPX4
Fully nitrogen purged to eliminate any fogging of the lenses internally
Turret Lock System, pull up for adjustment, press down for lock
High quality 6061 T6 aircraft grade aluminum
Focus mark: 10, 15, 25, 50, 100, 200, 500 and infinite
Diopter compensation from the fast-focus eyepiece (+2 to -2)
Including items: 30mm weaver, flip-up caps, honeycomb shade and cleaning cloth, etc.
