· Objective Lens Focus, 1/4MOA Turret Lock, 25.4mm 1in Monotube.
· Red and Green Illumination, Long Eye Relief, Mil-dot Style Reticle.
· Min Focus 3 Yards, Ultra Compact Size, Sunshade and Flip-up Caps.
| Magnification | 3-9x |
| Objective Lens Dia | 32 mm |
| Focal Plane | Second Focal Plane |
| Eye Relief | 102-76 mm / 4.0-3.0 in |
| Exit Pupil | 10.6-3.6 mm |
| Lens Coating | Fully multi-coated |
| Linear Field of View @ 100 yd | 37.0-12.5 ft @ 100 yards |
| Linear Field of View @ 100 m | 12.34-4.17 m @ 100 meters |
| Angular Field of View | 7.07-2.39° |
| Reticle | Mil-dot style |
| Tube Dia | 25.4 mm |
| Parallax Setting | 3 yards to infinity |
| Click Value | 1/4 MOA |
| Turret Function | Turret Lock |
| Elevation Adjustment Range | 120 MOA |
| Windage Adjustment Range | 120 MOA |
| Diopter Compensation | |
| Illumination Setting | Red & Green |
| Battery Type(NOT INCLUDE) | CR1620 |
| Waterproof | IPX4 |
| Fogproof | Nitrogen Filled |
| Shockproof | 750 G |
| Housing Material | 6061-T6 Aluminum Alloy |
| Finish | Matte Black |
| Length | 205 mm / 8.1 in |
| Weight (Net) | 385 g / 13.6 oz |
| Items in the Package | One Pair of 25.4mm 1in Weaver Scope Rings, Sunshade, Flip-up Caps |
FEATURE
· Objective Lens Focus, 1/4MOA Turret Lock, 25.4mm 1in Monotube.
· Red and Green Illumination, Long Eye Relief, Mil-dot Style Reticle.
· Min Focus 3 Yards, Ultra Compact Size, Sunshade and Flip-up Caps.
SPECIFICATION
| Magnification | 3-9x |
| Objective Lens Dia | 32 mm |
| Focal Plane | Second Focal Plane |
| Eye Relief | 102-76 mm / 4.0-3.0 in |
| Exit Pupil | 10.6-3.6 mm |
| Lens Coating | Fully multi-coated |
| Linear Field of View @ 100 yd | 37.0-12.5 ft @ 100 yards |
| Linear Field of View @ 100 m | 12.34-4.17 m @ 100 meters |
| Angular Field of View | 7.07-2.39° |
| Reticle | Mil-dot style |
| Tube Dia | 25.4 mm |
| Parallax Setting | 3 yards to infinity |
| Click Value | 1/4 MOA |
| Turret Function | Turret Lock |
| Elevation Adjustment Range | 120 MOA |
| Windage Adjustment Range | 120 MOA |
| Diopter Compensation | |
| Illumination Setting | Red & Green |
| Battery Type(NOT INCLUDE) | CR1620 |
| Waterproof | IPX4 |
| Fogproof | Nitrogen Filled |
| Shockproof | 750 G |
| Housing Material | 6061-T6 Aluminum Alloy |
| Finish | Matte Black |
| Length | 205 mm / 8.1 in |
| Weight (Net) | 385 g / 13.6 oz |
| Items in the Package | One Pair of 25.4mm 1in Weaver Scope Rings, Sunshade, Flip-up Caps |
SIZE
RETICLE
DOWNLOAD
