· 30mm Monotube, Edge-to-Edge Image, Fully Multi Coated, >4" Long Eye Relief, >50MOA Adjustment Range.
· Wide F.O.V, Etched Glass MOA Reticle, 1/4 MOA Turret Lock Sys, Illuminated, Lapua Magnum 338 Approved.
| Magnification | 5-30x |
| Objective Lens Dia | 56 mm |
| Focal Plane | SFP |
| Eye Relief | 124-86 mm / 4.9-3.4 in |
| Lens Coating | Fully Multi-coated |
| Linear Field of View @ 100 yd | 19.93-3.3 ft @ 100 yards |
| Linear Field of View @ 100 m | 6.64-1.1 m @ 100 meters |
| Angular Field of View ° | 3.8-0.63° |
| Reticle | VPA-A |
| Side Focus | 20 yards to Infinity |
| Tube Dia | 30 mm |
| Click Value | 1/4 MOA |
| Turret Function | Turret Lock |
| Elevation Adjustment Range | >50 MOA |
| Windage Adjustment Range | >50 MOA |
| Diopter Compensation | -2 to +2 |
| Illumination Setting | 11 Gear Red |
| Battery Type | CR2032 (NOT INCLUDE) |
| Battery Life | N/A |
| Waterproof | IPX6 |
| Fogproof | Filled Nitrogen |
| Shockproof | 750 G |
| Material | 6061-T6 Aluminum Alloy |
| Finish | Matte Black |
| Length | 400 mm / 15.7 in |
| Weight | 820 g / 28.9 oz |
FEATURE
· 30mm Monotube, Edge-to-Edge Image, Fully Multi Coated, >4" Long Eye Relief, >50MOA Adjustment Range.
· Wide F.O.V, Etched Glass MOA Reticle, 1/4 MOA Turret Lock Sys, Illuminated, Lapua Magnum 338 Approved.
SPECIFICATION
| Magnification | 5-30x |
| Objective Lens Dia | 56 mm |
| Focal Plane | SFP |
| Eye Relief | 124-86 mm / 4.9-3.4 in |
| Lens Coating | Fully Multi-coated |
| Linear Field of View @ 100 yd | 19.93-3.3 ft @ 100 yards |
| Linear Field of View @ 100 m | 6.64-1.1 m @ 100 meters |
| Angular Field of View ° | 3.8-0.63° |
| Reticle | VPA-A |
| Side Focus | 20 yards to Infinity |
| Tube Dia | 30 mm |
| Click Value | 1/4 MOA |
| Turret Function | Turret Lock |
| Elevation Adjustment Range | >50 MOA |
| Windage Adjustment Range | >50 MOA |
| Diopter Compensation | -2 to +2 |
| Illumination Setting | 11 Gear Red |
| Battery Type | CR2032 (NOT INCLUDE) |
| Battery Life | N/A |
| Waterproof | IPX6 |
| Fogproof | Filled Nitrogen |
| Shockproof | 750 G |
| Material | 6061-T6 Aluminum Alloy |
| Finish | Matte Black |
| Length | 400 mm / 15.7 in |
| Weight | 820 g / 28.9 oz |
