Feature
-
Vector Optics Top Line Product That Can Compete Worldwide Famous Brand Optics
-
German Optical System by Using LaRee Lens & VePRO FMC, 90% Light Transmission
-
Very Little Distortion, Extra-Low Dispersion, Excellent for Dawn, Dusk Even at Night Shooting
-
True 6x Zoom Factor, Constant 4" Eye Relief without Inside Dark Ring Around Image
-
6 Levels Illumination, Side Focus Parallax Min Starts from 10 Yards to Infinite
-
Adjustment System Made of 7075 T6 That Never Snag on Anything or Never Get Turned
-
30mm Monotube, 1/4MOA Capped Adjustment with Return-to-Zero Turret Feature
-
Etched Glass VECON-CDM Reticle, Center Dot Illumination w/ Ditital Lines & Dots
-
Take Lapua Magnum 338 Recoil and All Fields of Application for Hunting, Sporting & Competition
Specification
-
Magnification:3-18x
-
Objective Lens Dia.:50mm
-
Ocular Lens Dia.:42mm (1.7 inch)
-
Ocular Lens Length:57mm (2.2 inch)
-
Exit Pupil:9.5-2.8mm
-
Optics Coating:Fully-multi coat diamond clear
-
Field of View:41.5-6.9 Feet @ 100 yards
-
Field of View:13.8-23.M@ 100 meters
-
Eye Relief: 100mm (4.0 inch)
-
Length: 338mm (13.3 inch)
-
Weight: 653g (23.0 ounce)
-
Tube Dia.: 30mm Monotube
-
Click Value: 1/4 MOA
-
Elevation Range: 75MOA
-
Windage Range: 75MOA
-
Parallax Setting: 100 yards
-
Side Focus: 10 Yds to infinite
-
Reticle:Etched glass VECON-CDM
-
Illumination: Six gear
-
Battery: CR2032
-
Distance between objective lens part and middle turret: 64mm (2.5 inch)
-
Length of middle turret part: 35mm (1.4 inch)
-
Distance between middle turret part to power ring: 59mm (2.3 inch)
-
Shock tested to 750g, water proof at 1m
-
Light transmission reach to 90%
-
Fully nitrogen purged to eliminate any fogging of the lenses internally
-
Adjusting plate is NOT fixed, after zero the scope pull up the turret and re-set it to zero
-
High quality 6061 T6 aircraft grade aluminum
-
Focus mark: 10,15, 20, 30, 50, 100, 200, 300, 500 and infinite
-
Diopter compensation from fast-focus eyepiece (+2 to -3)
-
Including items: 30mm picatinny high rings (default) or weaver or dovetail rings, lens cap and cleaning cloth etc.
