· 8x Zoom Factor, Ture 1x Power For Both-Eyes-Open Shooting Allows for a Wide Field of View.
· Fully Multi-coated Lens Greatly Improve Light Transmission, Presenting Edge-to-Edge Image.
· Featuring a Durable and Reliable 30mm Monotube Design, Most Mount Types Available.
· 1/10 MIL Capped Adjustment with Very Low Profile, Total >35MIL Adjustment Range.
| Magnification | 1-8x |
| Objective Lens | 24 mm |
| Focal Plane | First Focal Plane |
| Eye Relief | 90 mm |
| Exit Pupil | 8.0-3.0 mm |
| Lens Coating | Fully Multi-coated |
| Linear Field of View @ 100 yd | 116.6-14.8 ft @ 100 yards |
| Linear Field of View @ 100 m | 34.6-4.5 m @ 100 meters |
| Angular Field of View | 19.9-2.6° |
| Reticle | VCO-1 MIL |
| Tube Dia | 30 mm |
| Parallax Setting | 100 yards |
| Click Value | 1/10 MIL |
| Turret Function | Capped |
| Elevation Adjustment Range | >35 MIL |
| Windage Adjustment Range | >35 MIL |
| Diopter Compensation | +2 to -2 |
| Illumination Setting | 11 Gears |
| Battery Type | CR2032 (Not Include) |
| Waterproof | IPX7 |
| Fogproof | Nitrogen Filled |
| Shockproof | 1000 G |
| Housing Material | 6061 T6 Aluminum Alloy |
| Finish | Matte Black |
| Length | 274 mm / 10.79 in |
| Weight (net) | 500 g / 17.6 oz |
| Items in the Package | One Pair of 30mm Weaver Scope Rings, Lens Caps and Cleaning Cloth, Power Throw Lever, etc. |
FEATURE
· 8x Zoom Factor, Ture 1x Power For Both-Eyes-Open Shooting Allows for a Wide Field of View.
· Fully Multi-coated Lens Greatly Improve Light Transmission, Presenting Edge-to-Edge Image.
· Featuring a Durable and Reliable 30mm Monotube Design, Most Mount Types Available.
· 1/10 MIL Capped Adjustment with Very Low Profile, Total >35MIL Adjustment Range.
SPECIFICATION
| Magnification | 1-8x |
| Objective Lens | 24 mm |
| Focal Plane | First Focal Plane |
| Eye Relief | 90 mm |
| Exit Pupil | 8.0-3.0 mm |
| Lens Coating | Fully Multi-coated |
| Linear Field of View @ 100 yd | 116.6-14.8 ft @ 100 yards |
| Linear Field of View @ 100 m | 34.6-4.5 m @ 100 meters |
| Angular Field of View | 19.9-2.6° |
| Reticle | VCO-1 MIL |
| Tube Dia | 30 mm |
| Parallax Setting | 100 yards |
| Click Value | 1/10 MIL |
| Turret Function | Capped |
| Elevation Adjustment Range | >35 MIL |
| Windage Adjustment Range | >35 MIL |
| Diopter Compensation | +2 to -2 |
| Illumination Setting | 11 Gears |
| Battery Type | CR2032 (Not Include) |
| Waterproof | IPX7 |
| Fogproof | Nitrogen Filled |
| Shockproof | 1000 G |
| Housing Material | 6061 T6 Aluminum Alloy |
| Finish | Matte Black |
| Length | 274 mm / 10.79 in |
| Weight (net) | 500 g / 17.6 oz |
| Items in the Package | One Pair of 30mm Weaver Scope Rings, Lens Caps and Cleaning Cloth, Power Throw Lever, etc. |
