· Fully Multi Coated Reaches 85% Light Transmission Sharp Clear Image.
· 4 inch Long Eye Relief With Wide Field of View & Edge-to-Edge Image.
· Etched Glass MPN-1 MIL Reticle, Side Focus Minimal from 10 Yards.
· 1/10 MIL Low Profile Adjustment w Turret Lock & Re-Zero Feature Total 15MIL Range.
| Magnification | 3.5-10x |
| Objective Lens Dia | 44 mm |
| Focal Plane | Second Focal Plane |
| Eye Relief | 105-100 mm |
| Lens Coating | Fully Multi-Coated |
| Linear Field of View @ 100 yd | 32.9-11 ft @ 100 yards |
| Linear Field of View @ 100 m | 11-3.6 m @ 100 meters |
| Reticle | Etched Glass MPN-1 Reticle |
| Side Focus | 10 yards to infinity |
| Tube Dia | 30 mm |
| Click Value | 1/10 MIL |
| Turret Function | Turret Lock |
| Elevation Adjustment Range | 18 MIL |
| Windage Adjustment Range | 18 MIL |
| Diopter Compensation | +2 to -2 |
| Illumination Setting | N/A |
| Battery Type(NOT INCLUDE) | N/A |
| Battery Life | N/A |
| Waterproof | IPX4 |
| Fogproof | Filled Nitrogen |
| Shockproof | 1000 G |
| Housing Material | 6061-T6 Aluminum Alloy |
| Finish | Black Matte |
| Length | 343 mm / 13.5 in |
| Weight | 665 g / 23.5 oz |
| Items in the Package | Power Ring Lever Mount, One Pair of 30mm Weaver Scope Rings, Dark Silver Color 1cm Spare Turret, Golden 0.1 MRAD Spare Turret, Cleaning Cloth and Honeycomb Sunshade, etc. |
FEATURE
· Fully Multi Coated Reaches 85% Light Transmission Sharp Clear Image.
· 4 inch Long Eye Relief With Wide Field of View & Edge-to-Edge Image.
· Etched Glass MPN-1 MIL Reticle, Side Focus Minimal from 10 Yards.
· 1/10 MIL Low Profile Adjustment w Turret Lock & Re-Zero Feature Total 15MIL Range.
SPECIFICATION
| Magnification | 3.5-10x |
| Objective Lens Dia | 44 mm |
| Focal Plane | Second Focal Plane |
| Eye Relief | 105-100 mm |
| Lens Coating | Fully Multi-Coated |
| Linear Field of View @ 100 yd | 32.9-11 ft @ 100 yards |
| Linear Field of View @ 100 m | 11-3.6 m @ 100 meters |
| Reticle | Etched Glass MPN-1 Reticle |
| Side Focus | 10 yards to infinity |
| Tube Dia | 30 mm |
| Click Value | 1/10 MIL |
| Turret Function | Turret Lock |
| Elevation Adjustment Range | 18 MIL |
| Windage Adjustment Range | 18 MIL |
| Diopter Compensation | +2 to -2 |
| Illumination Setting | N/A |
| Battery Type(NOT INCLUDE) | N/A |
| Battery Life | N/A |
| Waterproof | IPX4 |
| Fogproof | Filled Nitrogen |
| Shockproof | 1000 G |
| Housing Material | 6061-T6 Aluminum Alloy |
| Finish | Black Matte |
| Length | 343 mm / 13.5 in |
| Weight | 665 g / 23.5 oz |
| Items in the Package | Power Ring Lever Mount, One Pair of 30mm Weaver Scope Rings, Dark Silver Color 1cm Spare Turret, Golden 0.1 MRAD Spare Turret, Cleaning Cloth and Honeycomb Sunshade, etc. |
SIZE
RETICLE
DOWNLOAD
