Feature
Fully Multi Coated, Edge-to-Edge Image No Inside Dark Ring Around Image
3x Zoom Factor,4" Eye Relief, 25.4mm 1 Inch Monotube Made of 6061 T6
1/4MOA Capped Adjustment, MOA Reticle, Wide Filed of View 8.0 to 2.3°
Specification
· Magnification: 2-7x
· Objective Lens Dia.: 32mm
· Ocular Lens Dia.: 34mm / 1.3 inch
· Ocular Lens Length: 61mm / 2.4 inch
· Exit Pupil: 16.0-4.6mm
· Optics Coating: Fully-multi coat
· Field of View: 8.0-2.15°
· Eye Relief: 108--98mm / 4.2-3.9 inch
· Length: 280mm / 11.0 inch
· Weight: 360g / 12.7 ounces
· Tube Dia.: 25.4mm (1â€? Monotube
· Click Value: 1/4 MOA
· Elevation Range: 60MOA
· Windage Range: 60MOA
· Parallax Setting: 100 yards
· Reticle: VOW-MOA
· Illumination: None
· Distance between objective lens part and middle turret: 34mm (1.4 inch)
· Length of middle turret part: 33mm (1.3 inch)
· Distance between middle turret part to power ring: 47mm (1.8 inch)
· Shock tested to 600g and water proof
· Fully nitrogen purged to eliminate any fogging of the lenses internally
· High quality 6061 T6 aircraft grade aluminum
· Diopter compensation from fast-focus eyepiece (+2 to -2)
· Including items: weaver rings (default) or dovetail rings, lens caps and cleaning cloth etc.
Reticle
