· Fully Multi Coated. Edge-to-Edge Image. Wide Filed of View. Side Focus Min 10 Yds.
· 4x Zoom Factor. 4 Inch Long Eye Relief. 25.4mm 1 Inch Monotube Made of 6061 T6.
· 1/4MOA Zero Reset & Turret Lock. Etched Glass BDC Reticle. Center Dot Illuminated.
| Magnification | 6-24x |
| Objective Lens Dia | 50 mm |
| Focal Plane | SFP |
| Eye Relief | 105-100 mm / 4.1-3.9 in |
| Lens Coating | Fully Multi-coated |
| Linear Field of View @ 100 yd | 15.8-4.0 ft @100 yards |
| Linear Field of View @ 100 m | 5.26-1.33 m @100 meters |
| Angular Field of View ° | 3-0.76° |
| Reticle | VOI-10BDC |
| Parallax Setting | 10 yards to infinity |
| Tube Dia | 25.4 mm |
| Click Value | 1/4 MOA |
| Turret Function | Zero Reset & Turret Lock |
| Elevation Adjustment Range | 40 MOA |
| Windage Adjustment Range | 40 MOA |
| Diopter Compensation | -2 to +2 |
| Illumination Setting | 11 levels red+ 1 level NV |
| Battery Type | CR2032 (NOT INCLUDE) |
| Battery Life | N/A |
| Waterproof | IPX4 |
| Fogproof | Filled Nitrogen |
| Shockproof | 750 G |
| Housing Material | 6061-T6 Aluminum Alloy |
| Finish | Matte Black |
| Length | 362 mm / 14.25 in |
| Weight | 680 g / 24.0 oz |
| Items in the Package | One Pair of 25.4mm Weaver Scope Rings, Flip-up caps, Sunshade and Cleaning Cloth, etc. |
FEATURE
· Fully Multi Coated. Edge-to-Edge Image. Wide Filed of View. Side Focus Min 10 Yds.
· 4x Zoom Factor. 4 Inch Long Eye Relief. 25.4mm 1 Inch Monotube Made of 6061 T6.
· 1/4MOA Zero Reset & Turret Lock. Etched Glass BDC Reticle. Center Dot Illuminated.
SPECIFICATION
| Magnification | 6-24x |
| Objective Lens Dia | 50 mm |
| Focal Plane | SFP |
| Eye Relief | 105-100 mm / 4.1-3.9 in |
| Lens Coating | Fully Multi-coated |
| Linear Field of View @ 100 yd | 15.8-4.0 ft @100 yards |
| Linear Field of View @ 100 m | 5.26-1.33 m @100 meters |
| Angular Field of View ° | 3-0.76° |
| Reticle | VOI-10BDC |
| Parallax Setting | 10 yards to infinity |
| Tube Dia | 25.4 mm |
| Click Value | 1/4 MOA |
| Turret Function | Zero Reset & Turret Lock |
| Elevation Adjustment Range | 40 MOA |
| Windage Adjustment Range | 40 MOA |
| Diopter Compensation | -2 to +2 |
| Illumination Setting | 11 levels red+ 1 level NV |
| Battery Type | CR2032 (NOT INCLUDE) |
| Battery Life | N/A |
| Waterproof | IPX4 |
| Fogproof | Filled Nitrogen |
| Shockproof | 750 G |
| Housing Material | 6061-T6 Aluminum Alloy |
| Finish | Matte Black |
| Length | 362 mm / 14.25 in |
| Weight | 680 g / 24.0 oz |
| Items in the Package | One Pair of 25.4mm Weaver Scope Rings, Flip-up caps, Sunshade and Cleaning Cloth, etc. |
